Siemens SIPROCESS GA700 Quick Start

Technical specifications
11.4 Technical specifications of analyzer modules
126
Quick Start
Compact Operating Instructions, 05/2018, A5E31805656-06
Influence variables
Deviation of the span gas ≤ 0.5% of the current measuring span/10 K or
≤ 50 vpm O
2
/10 K;
whichever is greater
Sample gas pressure
Deviation at zero point ≤ 0.2% of the smallest measuring span/1% pressure
change or
≤ 50 vpm O
2
/1% pressure change;
whichever is greater
Deviation of the span gas Deviation ≤ 0.2% of current measuring span/1% pressure
change or
50 vpm O
2
/1% pressure change;
whichever is greater
Sample gas flow
Deviation at zero point ≤ 1% of smallest measuring span per 0.1 l/min. change in
flow or
50 vpm O
2
per 0.1 l/min. change in flow within the permissi-
ble flow range (0.3 to 1 l/min);
whichever is greater
Deviation of the span gas ≤ 1% of current measuring span per 0.1 l/min. change in
flow or
50 vpm O
2
per 0.1 l/min. change in flow within the permissi-
ble flow range (0.3 to 1 l/min.);
whichever is greater
Accompanying gases Zero point deviation (cross-sensitivity) in accordance with
Table A.1 of EN 61207-3
Supply voltage
Analyzer module 24 V DC
(-5%/+10%)
< 0.1% of the current span
Basic device
85 V AC to 264 V AC / 47 Hz to
63 Hz
< 0.1% of the current span
Table 11- 19 OXYMAT 7: Climatic conditions
Climatic conditions
Storage and transport
-30 to +70 °C
Max. permissible ambient temperature
surrounding the basic device during
operation
1)
0 to 50 °C
Ambient humidity (relative humidity)
during storage, transport or operation
2)
< 90%
1)
Restriction for installing an ULTRAMAT 7 analyzer module: 5 to 45 °C
2)
Avoid condensation on the installed components!
