Siemens SIPROTEC 7SJ62 Technical Data

Modbus register map
7SJ61/62/63 6MD63 – Modbus
C53000-L1840-C001-01
6-4
Register
address
Designation of the
SIPROTEC objects
Comments
Internal
object no.
00017 Switching device D4 (UsrDC4)
ON
00018 Switching device D4 (UsrDC4)
OFF
Impulse output,
2 relays, 1-pole
–
00019
–
00032
reserved
2
–
6.3.2 Register addresses 00033 to 00054: Single commands
•
Data type definition ref. to chap. 5.1.
Register
address
Designation of the
SIPROTEC objects
Comments
Internal
object no.
00033 Output channel E1 (UsrSC1) Impulse output, single command with checkback
indiation, 1 relay, 1-pole
–
00034 Output channel E2 (UsrSC2) Impulse output, single command with checkback
indiation, 1 relay, 1-pole
–
00035 Output channel E3 (UsrSC3) Impulse output, single command with checkback
indiation, 1 relay, 1-pole
–
00036 Output channel E4 (UsrSC4) Impulse output, single command with checkback
indiation, 1 relay, 1-pole
–
00037 Output channel E5 (UsrSC5) Impulse output, single command without
checkback indiation, 1 relay, 1-pole
–
00038 Output channel E6 (UsrSC6) Impulse output, single command without
checkback indiation, 1 relay, 1-pole
–
00039 Output channel E7 (UsrSC7) Impulse output, single command without
checkback indiation, 1 relay, 1-pole
–
00040 Output channel E8 (UsrSC8) Impulse output, single command without
checkback indiation, 1 relay, 1-pole
–
00041 Output channel E9 (UsrSC9) Impulse output, single command without
checkback indiation, 1 relay, 1-pole
–
00042 Output channel E10 (UsrSC10) Continuous output without restauration after
reset, SC without checkback indiation
–
00043 Output channel E11 (UsrSC11) Continuous output without restauration after
reset, SC without checkback indiation
–
00044 Output channel E12 (UsrSC12) Continuous output with restauration after reset,
SC without checkback indiation
–
00045 Output channel E13 (UsrSC13) Continuous output with restauration after reset,
SC without checkback indiation
–
00046 Output channel E14 (UsrSC14) Impulse output, single command without
checkback indiation, 1 relay, 1-pole
–
00047 Output channel E15 (UsrSC15) Impulse output, single command without
checkback indiation, 1 relay, 1-pole
–
00048 Output channel E16 (UsrSC16) Impulse output, single command without
checkback indiation, 1 relay, 1-pole
–
00049 Output channel E17 (UsrSC17) Impulse output, single command without
checkback indiation, 1 relay, 1-pole
–
00050 Output channel E18 (UsrSC18) Impulse output, single command without
checkback indiation, 1 relay, 1-pole
–
00051 Output channel E19 (UsrSC19) Impulse output, single command without
checkback indiation, 1 relay, 1-pole
–
00052 Output channel E20 (UsrSC20) Impulse output, single command without
checkback indiation, 1 relay, 1-pole
–
00053 Output channel E21 (UsrSC21) Continuous output without restauration after
reset, SC without checkback indiation
–
00054 Output channel E22 (UsrSC22) Continuous output without restauration after
reset, SC without checkback indiation
–
00055
–
00064
reserved
2
–
2
For an as "reserved" labeled coil status register the value 0 is always returned if reading.
A write access is rejected in the SIPROTEC device.
