Modbus register map
7SJ61/62/63 6MD63 - Modbus
C53000-L1840-C001-01
6-19
Register
address
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10324 66 ACTIVE 1 = 66 Motor start protection is ACTIVE 4826
10325 66 TRIP 1 = 66 Motor start protection TRIP 4827
10326
-
10336
reserved
4
–
6.4.13 Register addresses 10337 to 10342: Startup supervision
Register
address
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10337 START-SUP OFF 1 = Startup supervision is switched OFF 6811
10338 START-SUP BLK 1 = Startup supervision is BLOCKED 6812
10339 START-SUP ACT 1 = Startup supervision is ACTIVE 6813
10340 START-SUP TRIP 1 = Startup supervision TRIP 6821
10341 Rotor locked 1 = Rotor locked 6822
10342 START-SUP pu 1 = Startup supervision Pickup 6823
10343
–
10352
reserved
4
–
6.4.14 Register addresses 10353 to 10359: Trip coil monitor
Register
address
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10353 >74TC trip rel. 1 = >74TC Trip circuit superv.: trip relay 6852
10354 >74TC brk rel. 1 = >74TC Trip circuit superv.: bkr relay 6853
10355 74TC OFF 1 = 74TC Trip circuit supervision is switched
OFF
6861
10356 74TC BLOCKED 1 = 74TC Trip circuit supervision is BLOCKED 6862
10357 74TC ACTIVE 1 = 74TC Trip circuit supervision is ACTIVE 6863
10358 74TC ProgFail 1 = 74TC blocked. Binary input is not set. 6864
10359 FAIL: Trip cir. 1 = 74TC Failure Trip Circuit 6865
10360
–
10368
reserved
4
–
6.4.15 Register addresses 10369 to 10383: Inrush stabilization
Register
address
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10369 50-1 InRushPU 1 = 50-1 InRush picked up 7551
10370 50N-1 InRushPU 1 = 50N-1 InRush picked up 7552
10371 51 InRushPU 1 = 51 InRush picked up 7553
