Modbus register map
7SJ61/62/63 6MD63 - Modbus
C53000-L1840-C001-01
6-9
6.4 Input status registers (1X references)
The input status register block allows the Modbus master to scan the
current status of the input channels as well as the annunciations
generated in the SIPROTEC device (e.g. protection annunciations,
status annunciations).
Note
The allocation of the input channels to the binary inputs is defined during
parameterization of the devices.
Depending on the device composition and the existing protection
packages not all of the indicated binary inputs or protection
annunciations (and corresponding Modbus registers) may be available in
the SIPROTEC device.
Ref. to chap. 5.1 for data type definition of the input status registers.
6.4.1 Register addresses 10001 to 10037: Input channels with allocation to the
binary inputs
Register
address
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10001 Input channel 1 (UsrSpO/C1) Single-point indication OPEN/CLOSE
10002 Input channel 2 (UsrSpO/C2) Single-point indication OPEN/CLOSE
10003 Input channel 3 (UsrSpO/C3) Single-point indication OPEN/CLOSE
10004 Input channel 4 (UsrSpO/C4) Single-point indication OPEN/CLOSE
10005 Input channel 5 (UsrSpO/C5) Single-point indication OPEN/CLOSE
10006 Input channel 6 (UsrSpO/C6) Single-point indication OPEN/CLOSE
10007 Input channel 7 (UsrSpO/C7) Single-point indication OPEN/CLOSE
10008 Input channel 8 (UsrSpO/C8) Single-point indication OPEN/CLOSE
10009 Input channel 9 (UsrSpO/C9) Tagging / internal single-point indication
OPEN/CLOSE
10010 Input channel 10 (UsrSpO/C10) Tagging / internal single-point indication
OPEN/CLOSE
10011 Input channel 11 (UsrSpO/O11) Single-point indication ON/OFF
10012 Input channel 12 (UsrSpO/O12) Single-point indication ON/OFF
10013 Input channel 13 (UsrSpO/O13) Single-point indication ON/OFF
10014 Input channel 14 (UsrSpO/O14) Single-point indication ON/OFF
10015 Input channel 15 (UsrSpO/O15) Single-point indication ON/OFF
10016 Input channel 16 (UsrSpO/O16) Single-point indication ON/OFF
10017 Input channel 17 (UsrSpO/O17) Single-point indication ON/OFF
10018 Input channel 18 (UsrSpO/O18) Single-point indication ON/OFF
