Modbus register map
7SJ61/62/63 6MD63 – Modbus
C53000-L1840-C001-01
6-18
6.4.10 Register addresses 10289 to 10298: Circuit breaker failure protection
Register
address
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10289 >BLOCK 50BF 1 = >BLOCK 50BF 1403
10290 >50BF ext SRC 1 = >50BF initiated externally 1431
10291 50BF OFF 1 = 50BF is switched OFF 1451
10292 50BF BLOCK 1 = 50BF is BLOCKED 1452
10293 50BF ACTIVE 1 = 50BF is ACTIVE 1453
10294 50BF int Pickup 1 = 50BF (internal) PICKUP 1456
10295 50BF ext Pickup 1 = 50BF (external) PICKUP 1457
10296 50BF TRIP 1 = 50BF TRIP 1471
10297 50BF int TRIP 1 = 50BF (internal) TRIP 1480
10298 50BF ext TRIP 1 = 50BF (external) TRIP 1481
10299
-
103004
reserved
4
–
6.4.11 Register addresses 10305 to 10313: Thermal overload protection
Register
address
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10305 BLOCK 49 O/L 1 = >BLOCK 49 Overload Protection 1503
10306 49 EmergencyStart 1 = >Emergency start of motors 1507
10307 49 O/L OFF 1 = 49 Overload Protection is switched OFF 1511
10308 49 O/L BLOCK 1 = 49 Overload Protection is BLOCKED 1512
10309 49 O/L ACTIVE 1 = 49 Overload Protection is ACTIVE 1513
10310 49 O/L I Alarm 1 = 49 Overload Current Alarm (I alarm) 1515
10311 49 O/L <Theta> Alarm 1 = 49 Overload Alarm! Near Thermal Trip 1516
10312 49 Winding O/L 1 = 49 Winding Overload 1517
10313 49 Th O/L TRIP 1 = 49 Thermal Overload TRIP 1521
10314
-
10320
reserved
4
–
6.4.12 Register addresses 10321 to 10325: Motor start protection
Register
address
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10321 >66 emerg.start 1 = >Emergency start 4823
10322 66 OFF 1 = 66 Motor start protection is switched OFF 4824
10323 66 BLOCKED 1 = 66 Motor start protection is BLOCKED 4825
