Modbus register map
7SJ61/62/63 6MD63 – Modbus
C53000-L1840-C001-01
6-12
Register
address
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10082 79 L-L Sequence 1 = 79-A/R multi-phase reclosing sequence 2879
10083 >ZSC ON 1 = >Switch zone sequence coordination ON 2722
10084 >ZSC OFF 1 = >Switch zone sequence coordination OFF 2723
10085 TRIP Gnd Fault 1 = TRIP Ground Fault 2869
10086 TRIP Ph Fault 1 = TRIP Phase Fault 2870
10087 ZSC active 1 = Zone Sequencing is active 2883
10088 ZSC ON 1 = Zone sequence coordination switched
ON
2884
10089 ZSC OFF 1 = Zone sequence coordination switched
OFF
2885
10090
10096
reserved
4
6.4.4 Register addresses 10097 to 10137: Time overcurrent protection
Register
address
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10097 >BLOCK 50-2 1 = >BLOCK 50-2 1721
10098 >BLOCK 50-1 1 = >BLOCK 50-1 1722
10099 >BLOCK 51 1 = >BLOCK 51 1723
10100 >BLOCK 50N-2 1 = >BLOCK 50N-2 1724
10101 >BLOCK 50N-1 1 = >BLOCK 50N-1 1725
10102 >BLOCK 51N 1 = >BLOCK 51N 1726
10103 >BLK CLP stpTim 1 = >BLOCK Cold-Load-Pickup stop timer 1731
10104 50/51 PH OFF 1 = 50/51 O/C is switched OFF 1751
10105 50/51 PH BLK 1 = 50/51 O/C is BLOCKED 1752
10106 50/51 PH ACT 1 = 50/51 O/C is ACTIVE 1753
10107 50N/51N OFF 1 = 50N/51N is switched OFF 1756
10108 50N/51N BLK 1 = 50N/51N is BLOCKED 1757
10109 50N/51N ACT 1 = 50N/51N is ACTIVE 1758
10110 50(N)/51(N) PU 1 = 50(N)/51(N) O/C PICKUP 1761
10111 50/51 Ph A PU 1 = 50/51 Phase A picked up 1762
10112 50/51 Ph B PU 1 = 50/51 Phase B picked up 1763
10113 50/51 Ph C PU 1 = 50/51 Phase C picked up 1764
10114 50N/51NPickedup 1 = 50N/51N picked up 1765
10115 50(N)/51(N)TRIP 1 = 50(N)/51(N) TRIP 1791
