7SJ61/62/63 6MD63 - Modbus
C53000-L1840-C001-01
6-5
Note
• The command output mode (pulse output, continuous output) is
changeable for the single commands using parametrization software
DIGSI. The command output modes indicated in above table are
predefined.
• The switching direction OFF for single commands with pulse output
is not permitted and is rejected in the SIPROTEC device.
• It is presupposed at single commands with pulse output and
checkback indication that a switchgear with monostable time
element is externally connected. This monoflop is activated by the
pulse command and drops out after a predefined time. Now a
repeated activation is possible. The command output is rejected in
the SIPROTEC device during the time in which the checkback
indication has the value ON.
6.3.3 Register addresses 00065 to 00071: Internal commands
•
Data type definition ref. to chap. 5.1.
Register
address
Designation of the
SIPROTEC objects
Comments
Internal
object no.
Command: Auto recl. ON/OFF
0 = Deactivation of “Autoreclosing“
1 = Activation of “Autoreclosing“
127
00065
Annunciation: 79AR ON
1 = AR is switched ON
2782
Command: Protection ON/OFF
0 = Deactivation of protection functions
1 = Activation of protection functions
126
00066
Annunciation: Prot.Active
1 = At least one protection function is active
52
Command: Setting group A
0 = not permissible
1 = Activation of setting group A
00067
Annunciation: Setting group A
0 = Setting group A is not active
1 = Setting group A is active
53
Command: Setting group B
0 = not permissible
1 = Activation of setting group B
00068
Annunciation: Setting group B
0 = Setting group B is not active
1 = Setting group B is active
54
Command: Setting group C
0 = not permissible
1 = Activation of setting group C
00069
Annunciation: Setting group C
0 = Setting group C is not active
1 = Setting group C is active
55
Command: Setting group D
0 = not permissible
1 = Activation of setting group A
00070
Annunciation: Setting group D
0 = Setting group D is not active
1 = Setting group D is active
56
Command: Mode REMOTE
Change control mode REMOTE to
0 = Control mode REMOTE = LOCKED
1 = Control mode REMOTE = UNLOCKED
00071
Annunciation: SchModFern
Status of control mode REMOTE
0 = LOCKED
1 = UNLOCKED
–
00072
–
00080
reserved
2
–
