Modbus register map
7SJ61/62/63 6MD63 – Modbus
C53000-L1840-C001-01
6-20
Register
address
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10372 51N InRushPU 1 = 51N InRush picked up 7554
10373 InRush OFF 1 = InRush is switched OFF 7556
10374 InRushPhBLOCKED 1 = InRush Phase is BLOCKED 7557
10375 InRush Gnd BLK 1 = InRush Ground is BLOCKED 7558
10376 67-1 InRushPU 1 = 67-1 InRush picked up 7559
10377 67N-1 InRushPU 1 = 67N-1 InRush picked up 7560
10378 67-TOC InRushPU 1 = 67-TOC InRush picked up 7561
10379 67N-TOCInRushPU 1 = 67N-TOC InRush picked up 7562
10380 Gnd InRush PU 1 = Ground InRush picked up 7564
10381 Ia InRush PU 1 = Phase A InRush picked up 7565
10382 Ib InRush PU 1 = Phase B InRush picked up 7566
10383 Ic InRush PU 1 = Phase C InRush picked up 7567
10384 reserved
4
–
6.4.16 Register address 10385: Fault locator
Register
address
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10385 >Start Flt. Loc 1 = >Start Fault Locator 1106
10386
–
10392
reserved
4
–
6.4.17 Register addresses 10393 to 10396: Cold load pickup
Register
address
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10393 CLP OFF 1 = Cold-Load-Pickup is switched OFF 1994
10394 CLP BLOCKED 1 = Cold-Load-Pickup is BLOCKED 1995
10395 CLP running 1 = Cold-Load-Pickup is RUNNING 1996
10396 Dyn set ACTIVE 1 = Dynamic settings are ACTIVE 1997
10397
–
10400
reserved
4
–
