Modbus register map
7SJ61/62/63 6MD63 – Modbus
C53000-L1840-C001-01
6-6
Control mode REMOTE
Control mode with control authority is REMOTE, option of unlocked
control with Modbus.
• Changing the “Control mode REMOTE“ to UNLOCKED permits one
unlocked control operation via Modbus. After execution of the
command, the tagging “Control mode REMOTE“ in the SIPROTEC
device will automatically be reset to LOCKED.
• A programmed test “Switch in position“ for unlocked control
operations will always be executed.
• If, after changing the “Control mode REMOTE“ to UNLOCKED, no
command is received via Modbus for a period of 5 minutes, then the
tagging “Control mode REMOTE“ is automatically reset to LOCKED.
Changing the setting group
In order to change the setting group, the value “1“ = ON must be
transmitted to the corresponding register. Switching on one setting group
automatically switches off the current active setting group. Transmission
of the value “0“ = OFF is insignificant for the change of the setting group
and is refused by the device.
A change of the setting group is only possible via Modbus if the
parameter C
HANGE TO
A
NOTHER
S
ETTING
G
ROUP
(parameter address =
302) has the value "Protocol".
6.3.4 Register addresses 00081 to 0096: Application logic CFC
•
Data type definitions ref. to chap. 5.1.
Register
address
Designation of the
SIPROTEC objects
Comments
Internal
object no.
00081 CFC-Incoming annunciation 1
(UsCfcSpI1)
Tagging ON/OFF,
released as CFC input
–
00082 CFC-Incoming annunciation 2
(UsCfcSpI2)
Tagging ON/OFF,
released as CFC input
–
00083 CFC-Incoming annunciation 3
(UsCfcSpI3)
Tagging ON/OFF,
released as CFC input
–
00084 CFC-Incoming annunciation 4
(UsCfcSpI4)
Tagging ON/OFF,
released as CFC input
–
00085 CFC-Incoming annunciation 5
(UsCfcSpI5)
Tagging ON/OFF,
released as CFC input
–
00086 CFC-Incoming annunciation 6
(UsCfcSpI6)
Tagging ON/OFF,
released as CFC input
–
00087 CFC-Incoming annunciation 7
(UsCfcSpI7)
Tagging ON/OFF,
released as CFC input
–
00088 CFC-Incoming annunciation 8
(UsCfcSpI8)
Tagging ON/OFF,
released as CFC input
–
00089 CFC-Incoming annunciation 9
(UsCfcSpI9)
Tagging ON/OFF,
released as CFC input
–
00090 CFC-Incoming annunciation 10
(UsCfcSpI10)
Tagging ON/OFF,
released as CFC input
–
00091 CFC-Incoming annunciation 11
(UsCfcSpI11)
Tagging ON/OFF,
released as CFC input
–
