Modbus register map
7SJ61/62/63 6MD63 - Modbus
C53000-L1840-C001-01
6-15
Register
address
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10183 67/67N pickedup 1 = 67/67N picked up 2691
10184 67 A picked up 1 = 67/67-TOC Phase A picked up 2692
10185 67 B picked up 1 = 67/67-TOC Phase B picked up 2693
10186 67 C picked up 1 = 67/67-TOC Phase C picked up 2694
10187 67N picked up 1 = 67N/67N-TOC picked up 2695
10188 67/67N TRIP 1 = 67/67N TRIP 2696
10189
–
10192
reserved
4
–
6.4.6 Register addresses 10193 to 10200: Unbalanced load protection
Register
address
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10193 >BLOCK 46 1 = >BLOCK 46 5143
10194 46 OFF 1 = 46 is switched OFF 5151
10195 46 BLOCKED 1 = 46 is BLOCKED 5152
10196 46 ACTIVE 1 = 46 is ACTIVE 5153
10197 46-2 picked up 1 = 46-2 picked up 5159
10198 46-1 picked up 1 = 46-1 picked up 5165
10199 46-TOC pickedup 1 = 46-TOC picked up 5166
10200 46 TRIP 1 = 46 TRIP 5170
10201
–
10208
reserved
4
–
6.4.7 Register addresses 10209 to 10224: Frequency protection
Register
address
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10209 >BLOCK 81O/U 1 = >BLOCK 81O/U 5203
10210 >BLOCK 81-1 1 = >BLOCK 81-1 5206
10211 >BLOCK 81-2 1 = >BLOCK 81-2 5207
10212 >BLOCK 81-3 1 = >BLOCK 81-3 5208
10213 >BLOCK 81-4 1 = >BLOCK 81-4 5209
10214 81 OFF 1 = 81 is switched OFF 5211
10215 81 BLOCKED 1 = 81 is BLOCKED 5212
10216 81 ACTIVE 1 = 81 is ACTIVE 5213
10217 81-1 picked up 1 = 81-1 picked up 5232
