Modbus register map
7SJ61/62/63 6MD63 – Modbus
C53000-L1840-C001-01
6-14
Register
address
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10150 >BLOCK 67N-TOC 1 = >BLOCK 67N-TOC 2624
10151 Phase A forward 1 = Phase A forward 2628
10152 Phase B forward 1 = Phase B forward 2629
10153 Phase C forward 1 = Phase C forward 2630
10154 Phase A reverse 1 = Phase A reverse 2632
10155 Phase B reverse 1 = Phase B reverse 2633
10156 Phase C reverse 1 = Phase C reverse 2634
10157 Ground forward 1 = Ground forward 2635
10158 Ground reverse 1 = Ground reverse 2636
10159 67-2 picked up 1 = 67-2 picked up 2642
10160 67N-2 picked up 1 = 67N-2 picked up 2646
10161 67-2 Time Out 1 = 67-2 Time Out 2647
10162 67N-2 Time Out 1 = 67N-2 Time Out 2648
10163 67-2 TRIP 1 = 67-2 TRIP 2649
10164 67/67-TOC OFF 1 = 67/67-TOC is switched OFF 2651
10165 67 BLOCKED 1 = 67/67-TOC is BLOCKED 2652
10166 67 ACTIVE 1 = 67/67-TOC is ACTIVE 2653
10167 67N OFF 1 = 67N/67N-TOC is switched OFF 2656
10168 67N BLOCKED 1 = 67N/67N-TOC is BLOCKED 2657
10169 67N ACTIVE 1 = 67N/67N-TOC is ACTIVE 2658
10170 67-1 picked up 1 = 67-1 picked up 2660
10171 67-1 Time Out 1 = 67-1 Time Out 2664
10172 67-1 TRIP 1 = 67-1 TRIP 2665
10173 67-TOC pickedup 1 = 67-TOC picked up 2670
10174 67-TOC Time Out 1 = 67-TOC Time Out 2674
10175 67-TOC TRIP 1 = 67-TOC TRIP 2675
10176 67N-2 TRIP 1 = 67N-2 TRIP 2679
10177 67N-1 picked up 1 = 67N-1 picked up 2681
10178 67N-1 Time Out 1 = 67N-1 Time Out 2682
10179 67N-1 TRIP 1 = 67N-1 TRIP 2683
10180 67N-TOCPickedup 1 = 67N-TOC picked up 2684
10181 67N-TOC TimeOut 1 = 67N-TOC Time Out 2685
10182 67N-TOC TRIP 1 = 67N-TOC TRIP 2686
