Modbus register map
7SJ61/62/63 6MD63 - Modbus
C53000-L1840-C001-01
6-11
Register
address
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10057 CFC-Output indication 9
(UsCfcSpO9)
Single-point indication ON/OFF,
released as CFC output
10058 CFC-Output indication 10
(UsCfcSpO10)
Single-point indication ON/OFF,
released as CFC output
10059 CFC-Output indication 11
(UsCfcSpO11)
Single-point indication ON/OFF,
released as CFC output
10060 CFC-Output indication 12
(UsCfcSpO12)
Single-point indication ON/OFF,
released as CFC output
10061 CFC-Output indication 13
(UsCfcSpO13)
Single-point indication ON/OFF,
released as CFC output
10062 CFC-Output indication 14
(UsCfcSpO14)
Single-point indication ON/OFF,
released as CFC output
10063 CFC-Output indication 15
(UsCfcSpO15)
Single-point indication ON/OFF,
released as CFC output
10064 CFC-Output indication 16
(UsCfcSpO16)
Single-point indication ON/OFF,
released as CFC output
Note
The CFC-Output indications allow configuration of further protection
annunciations on Modbus registers, which are not contained in the
standard mapping.
6.4.3 Register addresses 10065 to 10089: Automatic recloser status
Register
address
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10065 >79 ON 1 = >79 ON 2701
10066 >79 OFF 1 = >79 OFF 2702
10067 >BLOCK 79 1 = >BLOCK 79 2703
10068 >79 T WAIT 1 = >79 T Wait (coordination control) 2705
10069 > 79 TRIP 1p 1 = >79 Ext. 1pole TRIP for internal A/R 2715
10070 > 79 TRIP 3p 1 = >79 Ext. 3pole TRIP for internal A/R 2716
10071 >Enable ANSI#-2 1 = >Enable 50/67-(N)-2 (override 79 blk) 2720
10072 >CB Ready 1 = >Circuit breaker READY for reclosing 2730
10073 79AR OFF 1 = 79 Auto recloser is switched OFF 2781
10074 reserved
4
10075 CB is NOT ready 1 = Circuit breaker is NOT ready 2784
10076 79 DynBlock 1 = 79 - Auto-reclose is dynamically BLOCKED 2785
10077 79 in progress 1 = 79 - in progress 2801
10078 79 Close 1 = 79 - Close command 2851
10079 79 Successful 1 = 79 - cycle successful 2862
10080 79 Lockout 1 = 79 - Lockout 2863
10081 79 L-N Sequence 1 = 79-A/R single phase reclosing sequence 2878
