Modbus register map
7SJ61/62/63 6MD63 - Modbus
C53000-L1840-C001-01
6-13
Register
address
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10116 50-2 picked up 1 = 50-2 picked up 1800
10117 50-2 TimeOut 1 = 50-2 Time Out 1804
10118 50-2 TRIP 1 = 50-2 TRIP 1805
10119 50-1 picked up 1 = 50-1 picked up 1810
10120 50-1 TimeOut 1 = 50-1 Time Out 1814
10121 50-1 TRIP 1 = 50-1 TRIP 1815
10122 51 picked up 1 = 51 picked up 1820
10123 51 TimeOut 1 = 51 Time Out 1824
10124 51 TRIP 1 = 51 TRIP 1825
10125 50N-2 picked up 1 = 50N-2 picked up 1831
10126 50N-2 TimeOut 1 = 50N-2 Time Out 1832
10127 50N-2 TRIP 1 = 50N-2 TRIP 1833
10128 50N-1 picked up 1 = 50N-1 picked up 1834
10129 50N-1 TimeOut 1 = 50N-1 Time Out 1835
10130 50N-1 TRIP 1 = 50N-1 TRIP 1836
10131 51N picked up 1 = 51N picked up 1837
10132 51N TimeOut 1 = 51N TimeOut 1838
10133 51N TRIP 1 = 51N TRIP 1839
10134 PhA InrushBlk 1 = Phase A trip blocked by inrush detection 1840
10135 PhB InrushBlk 1 = Phase B trip blocked by inrush detection 1841
10136 PhC InrushBlk 1 = Phase C trip blocked by inrush detection 1842
10137 INRUSH X-BLK 1 = Cross blk: PhX blocked PhY 1843
10138
–
10144
reserved
4
–
6.4.5 Register addresses 10145 to 10188: Directional time overcurrent
protection
Register
address
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10145 >BLOCK 67-2 1 = >BLOCK 67-2 2615
10146 >BLOCK 67N-2 1 = >BLOCK 67N-2 2616
10147 >BLOCK 67-1 1 = >BLOCK 67-1 2621
10148 >BLOCK 67-TOC 1 = >BLOCK 67-TOC 2622
10149 >BLOCK 67N-1 1 = >BLOCK 67N-1 2623
