1 Using PROFINET IO
1.1 General
10 SIPROTEC 4, Communication Module PROFINET IO, Communication Profile
C53000-L1840-C360-1, Edition 08.2012
1.1 General
Application
The Ethernet-based fieldbus protocol PROFINET IO is used in SIPROTEC 4 devices equipped with the
100 Mbit EN100 Ethernet module. The PROFINET IO communication protocol is defined in the standards
IEC 61158 and IEC 61748.
PROFINET IO is used as additional communication protocol in the EN100 besides the IEC 61850/GOOSE
protocol and can be used in parallel with this protocol (see Chapter 2.13).
PROFINET IO is used mainly in industrial energy automation.
Requirements
The SIPROTEC device you are using must support the PROFINET IO protocol. Refer to the associated device
manual in this context.
Enter the required settings using the DIGSI parameterization software, version 4.85 or higher.
To set the PROFINET IO protocol, DIGSI must contain the IEC 61850 station configurator.
The parameterization is described in Chapter 3.2.1.
Scope of Delivery
The following device variants with EN100 modules are available when using the PROFINET IO protocol:
• SIPROTEC device with integrated EN100 and implemented PROFINET IO protocol:
− SIPROTEC device with EN100-E+ (electrical bus interface): RJ45 connection for Ethernet
− SIPROTEC device with EN100-O+ (optical bus interface): LC connection, multimode fiber cable
• EN100 with implemented PROFINET IO protocol for retrofittings at existing devices or for replaced EN100
modules:
− EN100-E+ (electrical bus interface): RJ45 connection for Ethernet;
order no. C53207-A351-D688-1
− EN100-O+ (optical bus interface): LC connection, multimode fiber cable;
order no. C53207-A351-D689-1
The following manuals provide detailed information on the EN100 module and the IEC 61850 protocol:
• German edition: Handbuch Ethernetmodul EN100, Bestellnr. C53000-G1100-C167-x
• English edition: Manual Ethernet Module EN100, order no. C53000-G1140-C167-x
Extended Scope of Delivery
In addition to the scope of delivery mentioned previously, you can download the following components from the
Internet:
• PROFINET IO firmware as PCK file
• PROFINET IO GSDML file
• MIB files for SNMP
• Various manuals: communication profile, bus mapping files
NOTE
In this manual, the following short forms are used: EN100 for the 100 Mbit EN100 Ethernet module, SIPROTEC
for SIPROTEC 4, and DIGSI for the DIGSI 4 parameterization software.
