2 PROFINET IO in SIPROTEC
2.4 IO Modules
37SIPROTEC 4, Communication Module PROFINET IO, Communication Profile
C53000-L1840-C360-1, Edition 08.2012
IO Module Double Commands 08
IO Module Event List Data
Double commands 08
Category in the hardware catalog Output data
Data type 8 double commands; see Chapter 2.3.3
Data size 2 bytes
Acyclic reading/writing of data None
Parameters None
Event list
Category in the hardware catalog Event list
Data type Message blocks and control bytes for event list; see
Chapter 2.3.6
Data size 32 bytes input and 2 bytes output
Acyclic reading/writing of data None
Parameters None
com_profinet-io_profile_us.book Page 37 Friday, August 17, 2012 1:40 PM
