① Insert the connectors on the link module into the corresponding main conductor terminals on the
contactor. Make sure the guide tabs are inserted into the slots on the contactor.
The link module will sit ush with the contactor on the left- and right-hand sides.
Mounting
7.3 Assembly and disassembly with dierent mounting systems
SIRIUS 3RA Load Feeders
Equipment Manual, 02/2022, A5E03656507520A/RS-AC/004 101
