④ Take the link module o the contactor.
Figure 7-10 Disassembling an S00 load feeder with spring-loaded connection system
Note
Proceed in the same way to disassemble the reversing starter (size S00).
Mounting
7.2 Mounting and disassembling load feeders
SIRIUS 3RA Load Feeders
Equipment Manual, 02/2022, A5E03656507520A/RS-AC/004 51
