SIRIUS 3RT2 contactors/contactor assemblies
2.9 Dimension drawings (dimensions in mm)
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
293
3RT2.2.-4 contactors (3-pole) in ring cable lug connection system with accessories mounted









$&'&
$&'&
1 Laterally mountable auxiliary switch block 3RH2921-4DA..
2 Auxiliary switch block for mounting on the front 3RH2911-4FA.. / -4GA.. / -4HA.. / -4NF..
Figure 2-50 3RT2.2.-4 contactors (ring cable lug connection system) with auxiliary switch blocks
mounted
Drilling plan for 3RT2.2. contactors




Figure 2-51 Drilling plan for 3RT2.2. contactors (size S0)
