SIRIUS 3RA21/22 load feeders
6.6 Mounting
SIRIUS Innovations
602 System Manual, 01/2011, A8E56203870002-03
Mounting the busbar adapter on the busbar
Attaching the busbar adapter to the busbar is a very straightforward process. The busbar
hooks on the rear of the adapter will hold the structure securely on the bar even under
severe ambient conditions.
Table 6- 23 Mounting the busbar adapter on the busbar
Step Operating instruction Figure
1 Press the button on the top of the busbar
adapter to release the holder. The holder
should flip out from the front of the busbar
adapter.


2 Attach the busbar adapter to the busbars
from above.


