SIRIUS 3RA21/22 load feeders
6.6 Mounting
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
603
Disassembly of the busbar adapter from the busbar system
The diagrams below illustrate how the busbar adapter is disassembled from the busbar
system:
Table 6- 24 Disassembling the busbar adapter from the busbar
Step Operating instruction Figure
1 From the front, insert a screwdriver
into the right-hand opening on the
busbar adapter and release the
holder. The button on the top of the
busbar adapter should spring up.



2 Remove the busbar adapter from the
busbars. To do this, you will first need
to push it up slightly so that you can
remove it by pulling it off toward you.


