Siemens SIROTEC System Manual

Hardware
6.6 Technical data
Hydraulic Drive
System Manual, 04/2015, 6SL3097-4BA00-0BP1
223
6.6
Technical data
Table 6- 18 Technical data, HLA module
6SL3420-2HX00-0AA0
Unit
Value
Electronics power supply
Voltage
Current
Power loss
V
DC
A
DC
W
20.4 … 28.8 (24 - 15 % + 20 %)
Max. 1.1 A
Max. 12 W
Supply of the hydraulic components
Voltage
Current
V
DC
A
DC
26.0 … 27.0 (26.5 ± 2 %)
Max. 8.5 A
Temperature range °C 0 … 55 (with derated output current for the
servo solenoid valves)
Max. cable lengths
to valves
to sensors
to the encoder (SSI, TTL)
m 40
DRIVE-CLiQ cables/encoder
m
100
24 V, 26.5 V and EP terminals
m
10
PE/ground connection
At the housing with M5/3 Nm screw
Weight (without mating connector)
kg
1.75 kg
Degree of protection
IP20
