Siemens SISTORE AX9 250 User Manual

Appendix
114
Siemens Building Technologies
Fire Safety & Security Products 03.2007
12.4.2 Recording times with 250 GB HDD (days) for NTSC images
Recording quality (standard resolution)
Recording speed
Very high (12 KB) High (8 KB) Standard (4 KB) Low (2 KB)
240 ips
1.0 1.5 3.0 6.0
120 ips
2.0 3.0 6.0 12.1
60 ips
4.0 6.0 12.1 24.1
30 ips
8.0 12.1 24.1 48.2
20 ips
12.1 18.1 36.2 72.3
15 ips
16.1 24.1 48.2 96.5
10 ips
24.1 36.2 72.3 144.7
5 ips
48.2 72.3 144.7 289.4
2.5 ips
96.5 144.7 289.4 578.7
1 ips
241.1 361.7 723.4 1,446.8
0.5 ips
482.3 723.4 1,446.8 2,893.5
0.25 ips
964.5 1,446.8 2,893.5 5,787.0
0.1 ips
2,411.3 3,616.9 7,233.8 14,467.6
Recording quality (high resolution)
Recording speed
Very high (24 KB) High (16 KB) Standard (8 KB) Low (4 KB)
120 ips
1.0 1.5 3.0 6.0
60 ips
2.0 3.0 6.0 12.1
30 ips
4.0 6.0 12.1 24.1
20 ips
6.0 9.0 18.1 36.2
15 ips
8.0 12.1 24.1 48.2
10 ips
12.1 18.1 36.2 72.3
5 ips
24.1 36.2 72.3 144.7
2.5 ips
48.2 72.3 144.7 289.4
1 ips
120.6 180.8 361.7 723.4
0.5 ips
241.1 361.7 723.4 1,446.8
0.25 ips
482.3 723.4 1,446.8 2,893.5
0.1 ips
1,205.6 1,808.4 3,616.9 7,233.8
NOTE
The ips (images per second) of the above table is not the configured recording speed per camera, but
the total number of recorded images per second. The values of the table represent the average case,
therefore it is not guaranteed, and it might be decreased while recording audio. Minimum 500 MB of
hard disk drive space a day for one channel is required for audio recording.
The SISTORE AX has a maximum recording speed of 200 images for PAL (240 images for NTSC) per
second (ips) with standard resolution and 100 images for PAL (120 images for NTSC) per second (ips)
with high resolution that will be applied globally depending on the number of cameras recorded.
