Configuration
43
Siemens Building Technologies
Fire Safety & Security Products 03.2007
8.6.2 LAN setup screen
Highlight LAN in the Network menu and press the button.
Î The LAN setup screen displays.
Fig. 35 LAN (Manual) setup screen
1. Highlight the box beside Type and press the
button.
Î You can select the type of network configuration from: Manual, DHCP and
ADSL (with PPPoE).
2. Select the desired type and press the
button.
Î Selecting "Manual" from the Type allows you to set up LAN parameters
manually.
NOTE
You will need to get the appropriate IP Address, Gateway and Subnet Mask from your network
administrator.
3. Change the numbers by highlighting them and using the Up and Down arrow
buttons to increase or decrease the number.
The factory default LAN settings are:
IP Address: 192.168.1.129
Gateway: 192.168.1.254
Subnet Mask: 255.255.255.0
4. Highlight the Port Number Setup… box and press the
button.
Î The Port Number Setup screen appears.
NOTE
You will need to get the appropriate Port Numbers for each RAS related program (Admin, Callback,
Watch and Search) from your network administrator.
Fig. 36 Port Numbers setup screen
