Technical data
15
Siemens Building Technologies
Fire Safety & Security Products 03.2007
3 Technical data
Video
Signal format PAL or NTSC (auto-detect)
Video input Composite: 9 or 16 looping inputs, 1 Vpp auto-terminating, 75 Ohms
Monitor outputs Composite: 1 (BNC), 1 Vpp, 75 Ohms
SVHS: 1
VGA: 1
- PAL: 30.8 kHz (horiz. frequency) / 50 Hz (vert. frequency)
- NTSC: 30.8 kHz (horiz. frequency) / 60 Hz (vert. frequency)
Video resolution PAL: 720 x 576
NTSC: 720 x 480
Playback/record speed
(images per second)
Standard resolution (CIF): 200 ips (PAL), 240 ips (NTSC)
High resolution (2CIF): 100 ips (PAL), 120 ips (NTSC)
Inputs / Outputs
Alarm input 9 or 16 TTL, programmable as NC or NO
Alarm output 9 or 16 TTL open collector, 5 mA @ 12 V / 30 mA @ 5 V
Alarm reset input 1x TTL
Internal buzzer 80 dB @ 10 cm
Network connectivity 10/100 Mbps Ethernet (RJ-45), RS-232C for external modem
Audio input RCA input: 4, Line In
Audio output RCA output: 1, Line Out
IR port 1 remote control
Connections
Video input Composite: 9 or 16 BNC
Video loop Composite: 9 or 16 BNC (auto-terminating)
Monitor output Composite: 1x BNC
SVHS: 1 Y/C *
VGA: 1 VGA
SPOT (composite): 4 BNC
Audio In 4 RCA connectors
Audio Out 1 RCA connector
Alarm input/output 16/16 push-button, terminal blocks
Ethernet port RJ-45
RS-232C serial port DB9 (P)
RS-485 serial port 2-connector terminal block
UltraWide SCSI port High-density female 68-pin connector
USB port 3 (USB 2.0)
Storage
Primary storage EIDE hard-disk drive (up to 3)
Built-in CD-RW or DVD-RW drive **
Secondary storage (optional) UltraWide SCSI hard-disk drive (RAID)
USB hard-disk drive, USB CD-RW drive or USB flash drive
