Operation
89
Siemens Building Technologies
Fire Safety & Security Products 03.2007
Clicking on the left side exits the toolbar. If you want to display the toolbar again,
position the mouse pointer at the bottom of the screen. Change the toolbar location
by clicking the empty space on the left side of the toolbar and drag it to where you
want it located on the screen. Use the arrow buttons on the toolbar to pan or tilt the
camera in the direction you want. The other controls on the toolbar perform as
described below:
Zoom In / Out
Focus Near / Far
Iris Open / Close
Set / Load Preset
9.2.5 Image adjustment
NOTE
It is important that cameras and monitors are correctly installed and adjusted prior to making any
image adjustments using the DVR’s controls.
If a user who has Colour Control authority logs into the system, the user can adjust
the image. Pressing and holding a camera button for a few seconds displays an
image adjustment dialog. You can control brightness, contrast, hue and saturation
for each camera.
NOTE
Any image adjustments you make will be applied to both the live video on the monitors and the
recorded video.
