Installation
20
Siemens Building Technologies
Fire Safety & Security Products 03.2007
7 Installation
The diagram below shows a typical DVR installation.
Fig. 1 Typical DVR installation
No special tools are required to install the DVR. Refer to the installation manuals
for the other items that make up part of your system.
Fig. 2 16-channel DVR rear panel
Your DVR can be used with either PAL or NTSC equipment.
NOTE
You cannot mix PAL and NTSC equipment. For example you cannot use a PAL camera and an NTSC
monitor.
