Configuration
73
Siemens Building Technologies
Fire Safety & Security Products 03.2007
8.10 Storage screen
Fig. 80 Storage Menu
8.10.1 Storage Information screen
Highlight Storage Information in the Storage menu and press the button.
Î The Storage Information setup screen appears and displays information about
the DVR’s storage devices.
Fig. 81 Storage Information screen
The information in the Type column describes the storage device.
The capacity of the storage device is displayed in the Capacity column.
The Format column displays whether the device is used for recording (Record) or
archiving (Archive). "Not Using" indicates the device is not used for either recording
or archiving. "Not formatted" indicates the device is not formatted.
indicates
when the device has temporary space set aside so that video clips can be saved
on a CD-RW or DVD-RW.
Highlight the box in the Format column for the desired storage device and press
the
button. You will be able to format the device for recording or archiving.
When selecting "Not Using" from Use As and highlighting the Format button, the
device will not be used for either recording or archiving. You can also set aside
space to store temporary files for CD or DVD burning by selecting Partition –
CD/DVD Burn.
Fig. 82 Device Format screen
