OPERATION 6
67
SITRANS FX330
www.siemens.com/flow08/2022 - A5E36751269-AG EN
6.7 Menu structure
6.7.1 Menu overview "A Quick Setup"
INFORMATION!
•
The following tables describe the functions of the standard device with HART
®
connection.
The functions for Foundation Fieldbus and Profibus are described in detail in the
corresponding supplementary instructions.
•
Depending on the device version, not all functions are available.
Meas. Menu A Submenus
> ↲ ↓ ↑ > ↲ ↓ ↑ > ↲ ↓ ↑
A Quick Setup A1 Language
A2 Contrast
A3 Login
A4 Tag
A5 Long Tag
A6 Message View
A7 Fluid
A8 Medium
A9 Units A9.1 Volume Flow A9.2 Cst. Vol. Flow
A9.3 Norm. Vol. Flow A9.4 Cst. N.Vol.Flow
A9.5 Mass Flow A9.6 Cst. Mass Flow
A9.7 Power A9.8 Cst. Power
A9.9 Volume A9.10 Cst. Volume
A9.11 Norm. Volume A9.12 Cst. Norm. Volume
A9.13 Mass A9.14 Cst. Mass
A9.15 Energy A9.16 Cst. Energy
A9.17 Pressure A9.18 Cst. Pressure
A9.19 Temperature A9.20 Cst. Temp.
A9.21 Density A9.22 Cst. Density
A10 Meter Type
A11 Application
Assistant
A11.1 Liquids
A11.2 Saturated Steam
A11.3 Superheated Steam
A11.4 Heat Measurement
A11.5 Gas
A11.6 FAD
A12 Cluster
Checks
Cluster 1...12
Table 6-17: Menu overview "A Quick Setup"
