Installing
4
4.1
Basic safety notes
WARNING
Exceeded maximum permissible operating pressure
Risk of injury or poisoning.
The maximum permissible operating pressure depends on the device version, pressure
limit and temperature rating. The device can be damaged if the operating pressure is
exceeded. Hot, toxic and corrosive process media could be released.
Ensure that maximum permissible operating pressure of the device is not exceeded. Refer
to the information on the nameplate and/or in Technical data (Page 45).
WARNING
Unsuitable connecting parts
Risk of injury or poisoning.
In case of improper mounting, hot, toxic, and corrosive process media could be released at
the connections.
• Ensure that connecting parts (such as flange gaskets and bolts) are suitable for
connection and process media.
See also
Technical data (Page 45)
CAUTION
Gasket between extension and protective tube
• Use gasket between device extension and protective tube only once.
WARNING
Incorrect mounting at Zone 0
Risk of explosion in hazardous areas.
• Ensure sufficient tightness at the process connection.
• Observe the standard IEC/EN 60079-14.

Siemens SITRANS TSinsert Specifications

General

Communication Protocol	HART
Type	Temperature Transmitter
Output Signal	4 to 20 mA, HART
Sensor	RTD, Thermocouple
Inputs	RTD, Thermocouple
Operating Temperature	-40 to 85 °C (-40 to 185 °F)
Protection Class	IP67
Display	Optional LCD display
