Page EN-6 ST-H Transducer – OPERATION MANUAL 7ML19985QK82
mmmmm
English
Specifications
* Approximate shipping weight of transducer with standard cable length.
** For chemical application check compatibility of ETFE or PVDF and epoxy, or mount joint external to process.
*** Performance available upon request.
ST-H Transducer
Measurement Range 0.3 - 10 m (1 - 33 ft)
Pressure vent to atmosphere
Supply Source transducer shall only be supplied by a Siemens Milltronics
certified controller
Frequency 44 kHz
Beam Angle 12°
Weight* 1.4 kg (3 lbs)
Separation 365 m (1200 ft) from transceiver
Environmental
Location indoor/outdoor
Altitude 2000 m (maximum)
Ambient Temperature -20 to +60 °C (-5 to +140 °F) (ATEX approved model)
-40 to +73 °C (-40 to +163 °F) (CSA/FM approved model)
Construction
Housing PVDF or ETFE base and lid (epoxy fitted joint)**
Mounting 2” NPT (Taper), R 2” (BSPT), or G 2" (BSPP) process
connection
Cable 2-core shielded/twisted, 0.519 mm
2
(20 AWG), PVC sheath
Options
• flange adapter, refer to associated instructions
• submergence coupling, refer to associated instructions
Approvals CE***, FM, ATEX, C-TICK, INMETRO,
CSA (ETFE only)
