XPS/XCT TRANSDUCER SERIES
CONNECTION DIAGRAM
0-9650017Z-DI-A
1
BG
PJF
TV
MC
AUG
13/1996
JULY
04/2012
NON - HAZARDOUS LOCATION
(SAFE)
HAZARDOUS LOCATION
FM CLASS I, DIV. 2, GROUPS A,B,C,D
FM CLASS II, DIV. 2, GROUPS F,G
SIEMENS
CONTROLLER
METAL CONDUIT
XPS / XCT SERIES
TRANSDUCER
1) INSTALLATION SHALL BE DONE IN ACCORDANCE WITH
THE NATIONAL ELECTRICAL CODE (N.E.C.).
2) NO REVISION SHALL BE MADE WITHOUT PRIOR FMRC AUTHORIZATION.
3) USE N.R.T.L. LISTED WATER TIGHT CONDUIT FITTING FOR OUTDOOR APPLICATIONS.
NOTE:
SEE
NOTE 3
