Siemens XPS - More XPS Series Model Details; XPS-30 Ultrasonic Transducer Details; XPS-40 Ultrasonic Transducer Details; Example Configuration and Serial Number Note

A5E32282889 XPS/XCT Series Transducers – OPERATION MANUAL Page EN-7
mmmmm
English
XPS-30
XPS-40
Note:
• Product configuration number shown for example only.
• Serial number shown for example only.
XPS-30 ULTRASONIC TRANSDUCER
Serial No: GYZ / A1034567
Ambient Temp.: – 40 °C to 95 °C
V in: 1.77 V r.m.s.; 250 Vp
Iin:44.2mAr.m.s.
Class I, Zone 1, Ex s I/IIC T4
DIP IP65 / 67
ANZEx 08.3066X
SIRA 99ATEX5153X
II 2G 1D
EExmIIT4
Siemens Milltronics Process Instruments, Peterborough
Enclosure: IP66, IP68
KCC-REM-S49
Echomax
Static Hazard, Do Not Rub With Dry Cloth.WARNING:
Ex mb IIC T4 Gb
Ex tb IIIC T135 °C Db
DNV 12.0077 X
Class I, Div 2, Group A, B, C, D
Class II, Div 1, Group E, F, G
Per Dwg.: 0-9650017Z-DI-A
Max. Torque: 15 FT–LBS (20 N-m)
ATENÇÃO - RISCO POTENCIAL DE CARGA
ELETROSTÁTICA - VEJA INSTRUÇÕES
OCP 0017
XPS-40 ULTRASONIC TRANSDUCER
Serial No: GYZ / A1034567
Ambient Temp.: – 40 °C to 95 °C
V in: 1.77 V r.m.s.; 250 Vp
I in : 44.2 mA r.m.s.
Class I, Zone 1, Ex s I/IIC T4
DIPIP65/67
ANZEx 08.3066X
SIRA 99ATEX5153X
II 2G 1D
EExmIIT4
Siemens Milltronics Process Instruments, Peterborough
Enclosure: IP66, IP68
KCC-REM-S49
Echomax
Static Hazard, Do Not Rub With Dry Cloth.WARNING:
Ex mb IIC T4 Gb
Ex tb IIIC T135 °C Db
DNV 12.0077 X
Class I, Div 2, Group A, B, C, D
Class II, Div 1, Group E, F, G
Per Dwg.: 0-9650017Z-DI-A
Max. Torque: 15 FT–LBS (20 N-m)
ATENÇÃO - RISCO POTENCIAL DE CARGA
ELETROSTÁTICA - VEJA INSTRUÇÕES
OCP 0017
