4.1.10. Factory Default Settings
Project ID: ‘Compact ‘
For each node:
• Measurement standard: S01
• Threshold: 2.0 mm/s (ON)
• Interval time: 120 seconds
• Transient time: 2 seconds
• Node ID: ‘GEO’
4.2. Mounting
Make sure that C12 is firmly attached and mounted with the antennas and
LEDs pointing up (see front page). For correct measuring results, the
mounting angle of the C12 instrument must not exceed 5º relative to the
horizontal plane. Refer to Sigicom product catalog for more information
on mounting solutions.
Note! C12 must not be submerged in water.
