2 SDG1000 Service Manual
Frequency Specification
SDG1005
SDG1010
SDG1020
SDG1025
SDG1050
Waveform
Sine, Square, Ramp, Pulse, Noise, Arb
Sine
1μHz ~5MHz
1μHz ~10MHz
1μHz ~ 20MHz
1μHz ~25MHz
1μHz ~50MHz
Square
1μHz ~ 5MHz
1μHz ~ 10MHz
1μHz ~ 20MHz
1μHz ~ 25MHz
1μHz ~ 25MHz
Pulse
500μHz~5MHz
500μHz ~ 10MHz
Ramp
1μHz ~ 300kHz
Gaussian white
noise
5MHz (-3dB)
10MHz (-3dB)
20MHz (-3dB)
25MHz (-3dB)
50MHz (-3dB)
Arbitrary waveform
1μHz ~5MHz
1μHz ~5MHz
1μHz ~5MHz
1μHz ~5MHz
1μHz ~ 5MHz
resolution
1 μHz
Accuracy
Within 90daysv±50 ppm within 1 year ±100 ppm 18°C ~ 28°C
Temperature
coefficient
<5 ppm/°C
Square Wave
Rise/fall time
< 12 ns（10% ~ 90%，typical value，1 kHz，1 Vpp）
Overshoot
< 5%（typical value，1kHz，1Vpp）
Duty Cycle
1μHz ~ 10 MHz
20% ~ 80%
10 MHz（exclude）~ 20 MHz
40% ~ 60%
20 MHz（exclude）~ 25 MHz
50%
Asymmetric（50% Duty Cycle）
1% of period + 20 ns（typical value, 1 kHz, 1Vpp）
Jitter
0.1% of period（typical value, 1 kHz, 1Vpp）
Sine Wave Spectrum Purity
Harmonic Distortion
CH1/CH2
DC ~ 1MHz
-60 dBc
1MHz ~5MHz
-53 dBc
5MHz ~25MHz
-35 dBc
25MHz ~50MHz
-32 dBc
Total harmonic waveform distortion
DC ~ 20 kHz，1 Vpp <0.2%
Spurious signal（non-harmonic）
DC ~ 1 MHz: < -70 dBc
1 MHz ~ 10 MHz :< -70 dBc + 6 dB/spectrum phase
Phase noise
10kHz Offset，–108 dBc / Hz （typical value）
