The Front Panel at a Glance
No.
Description
Description
1
ON/OFF Switch
Direction Keys
2
USB Host
Output Control Keys
3
LOGO
BNC Connectors
4
Model
Function Keys
5
Menu ON/OFF Switch
Waveform Selection Keys
6
Digital Keypad
Menu Operation Keys
7
Universal Knob
LCD Display
2
1
14 13 12 11 10
3 4 5 6 7
8
9
