SDG1000 Service Manual 11
Set the Output Frequency
The following steps show you how to change the frequency to 1.5 MHz.
1. Press the Freq/Period softkey
The displayed frequency is either the power-on value or the frequency
previously selected. When you change the function, the same frequency is
used if the current value is valid for the new waveform. If you want to set the
period for the waveform, press the softkey again, to switch the period
parameter(The current operation is displayed in inverse color).
2. Input the desired frequency
Use the digital keypad to input the value directly, enter the value “1.5”.
Then press the corresponding softkey to select the desired unit. For example,
press MHz.
Note: You can also enter the desired value using the knob and direction keys.
