28 SDG1000 Service Manual
◆ Minimize handling.
◆ Keep replacement parts in original static-free packaging.
◆ Remove all plastic, foam, vinyl, paper and other static-generating materials
from the immediate work area.
◆ Use only anti-static solder suckers.
List of Modules
The following removable modules are listed in the order of performing
disassembly procedures.
Required Tools
Use these tools to remove or replace the modules in the oscilloscope:
⚫ PH2 philips head screw drivers
Disassembly Procedures
This section describes how to remove and install the modules listed above in
the generator in detail. Complete disassembly will be best achieved through
the following operating steps.
