SDG1000 Service Manual 33

Removing the Front Cabinet

Table 4-6 Removing the front cabinet

Removing steps:

1. Remove the front module cable connected to the main board.

2. Remove the screws from the front cabinet using a PH2 philips screw driver.

3. Separate the front cabinet from the main body of the generator.

To install the front cabinet, please operate as the reverse steps.

Table 4-7 Disassembled into three parts
