SDG1000 Service Manual 7
General Specifications
Display
Display type
3.5’TFT-LCD
Resolution
320×RGB×240
Color depth
24 bit
Contrast（typical value）
350:1
Backlight intensity
(typical )
300cd/m
2
Power
Voltage
100 ~ 240 VAC
RMS
, 45 ~ 66 Hz, CATII
100 ~ 127 VAC
RMS
, 45 ~ 440 Hz, CATII
Consumption
＜ 30W
Fuse
1.25A, 250V
Environment
Temperature
Operation: 0°C ~ 40°C
Storage: -20°C ~ 60°C
Cooling method
natural cooling down
Temperature range
Below +35℃: ≤90％ relative humidity
+35℃ ~ +40℃: ≤60％ relative humidity
Altitude
Operation: below 3,000 meters
Storage: below 15,000 meters
Others
Dimension
Width: 229mm
Height: 105mm
Depth: 281mm
Weight
N.W: 2.6 Kg
G.W: 3.4 Kg
IP protection
IP2X
Calibration Cycle
1 year
