6 SDG1000 Service Manual
Frequency Counter
Measurement
Frequency, Period, Positive/negative pulse width, duty cycle
Frequency range
Single Channel: 100 mHz ~ 200 MHz
Frequency resolution
6 bit
Voltage range and sensitivity(non-modulated signal）
Manual
DC coupling
DC offset range
±1.5 VDC
100 mHz ~ 100 MHz
50mVrms ~ ±2.5 V
100 MHz ~ 200 MHz
100mVrms ~ ±2.5 V
AC coupling
1 Hz ~ 100 MHz
50m Vrms ~ 5 Vpp
100 MHz ~ 200 MHz
100m Vrms ~ 5 Vpp
Pulse width and duty
measurement
1 Hz ~ 10 MHz（100 mVpp ~ 10 Vpp）
Input adjustment
Input impedance
1 MΩ
Coupling methods
AC、DC
High-frequency rejection
ON/OFF
Trigger level range
-3V ~ +1.8V
