Specification
These specifications apply to SDG1000 series Arbitrary Waveform Generator.
To verify that an oscilloscope meets specifications, it must first meet the
following conditions:
⚫ The generator must have been operating continuously for fifteen minutes
within the specified operating temperature.
⚫ You must perform the Self Adjust operation, accessible through the Utility
menu, if the operating temperature changes by more than 5 °C.
⚫ The oscilloscope must be within the factory calibration interval of one year.
Specifications
Model
SDG1005
SDG1010
SDG1020
SDG1025
SDG1050
Max.output
frequency
5MHz
10MHz
20MHz
25MHz
50MHz
Output channels
2
Sample rate
125 MSa/s
Arbitrary
waveform length
16 kpts
Frequency resolution
1 μHz
vertical resolution
14 bits
Waveform
Sine, Square, Ramp, Pulse, Gaussian Noise, 46 types of built-in arbitrary waveform
Sine
1μHz ~ 5MHz
1μHz ~ 10MHz
1μHz ~20MHz
1μHz ~ 25MHz
1μHz ~ 50MHz
Square
1μHz ~ 5MHz
1μHz ~ 10MHz
1μHz ~20MHz
1μHz ~ 25MHz
1μHz ~ 25MHz
Pulse
500μHz~5MHz
500μHz ~10MHz
Ramp/Triangular
1μHz ~ 300KHz
Gaussian white noise
5MHz (-3dB)
10MHz (-3dB)
20MHz (-3dB)
25MHz (-3dB)
50MHz (-3dB)
Arbitrary waveform
1μHz ~ 5MHz
Modulation
AM, DSB-AM, FM, PM, FSK, ASK, PWM, Sweep, Burst
Frequency counter
Frequency range：100mHz ～ 200MHz
Standard interface
USB Host & Device
Dimension
W x H x D=229mm x 105mm x 281mm

SIGLENT TECHNOLOGIES SDG1032X Specifications

General

Brand	SIGLENT TECHNOLOGIES
Model	SDG1032X
Category	Portable Generator
Language	English
