SDG1000 Service Manual 5
Sweep（CH1/CH2）
Carrier
Sine, Square, Ramp, Arbitrary (except DC)
Type
linear/logarithmic
Direction
Up / down
Sweep time
1 ms ~ 500 s
Trigger source
Manual, external, internal
Burst（CH1/CH2）
Waveform
Sine, Square, Ramp, Pulse, Arbitrary(except DC)
Type
Count（1 ~ 50,000 cycles）， infinite，Gated
Start/Stop phrase
0° ~ +360°
Internal cycle
1 μs ~ 500 s
Gated trigger
External trigger
Trigger source
Manuel, External or Internal
Rear Panel Connector
External modulation
±6 Vpk = 100% modulation 5KΩ input impedance
External trigger
TTL compatible
The external input voltage can’t be over ±6V, otherwise instrument gets damaged.
Trigger Input
Voltage level input
TTL compatible
Slope
Up or down (optional)
Pulse width
> 100 ns
Input impedance
> 5 kΩ, DC coupling
Trigger Output
Voltage level
TTL compatible
Pulse width
> 400 ns （typical value）
Output impedance
50Ω （typical value）
Max. frequency
1 MHz
SYNC Output
Voltage level
TTL compatible
Pulse width
> 50 ns（typical value）
Output impedance
50Ω（typical value）
Max. frequency
2MHz
