130 SDG2000X User Manual
3.2 Example 2: Generate a Square Waveform
Generate a square waveform with 5kHz frequency, 2Vpp amplitude, 1Vdc
offset and 30% duty cycle.
 Steps:
 Set the frequency.
1. Press Waveforms → Square → Frequency/Period and choose Frequency
which will display in blue color.
2. Input ‘5’ from the keyboard and choose the unit ‘kHz’. The frequency is set
to 5kHz.
 Set the Amplitude.
1. Press Amplitude/HighLevel to choose Amplitude which will display in blue
color.
2. Input ‘2’ from the keyboard and choose the unit ‘Vpp’. The amplitude is set
to 2Vpp.
 Set the Offset.
1. Press Offset/LowLevel to choose Offset which will display in blue color.
2. Input ‘1’ from the keyboard and choose the unit ‘Vdc’. The offset is set to
1Vdc.
 Set the DutyCycle.
1. Press DutyCycle to choose DutyCycle which will display in blue color.
2. Input ‘30’ from the keyboard and choose the unit ‘%’. The duty is set to
30%.
When the frequency, amplitude, offset and duty cycle are set, the waveform
generated is shown in Figure 3-2.
