3.5 Example 5: Generate a Noise
Generate a noise with 0.5V stdev and 1 V mean.
Steps:
Set the Stdev.
1. Press Waveforms → Noise → Stdev to choose Stdev which will display in
blue color.
2. Input ‘0.5’ from the keyboard and choose the unit ‘V’. The stdev is set to
0.5 V.
Set the Mean.
1. Press Mean to choose Mean which will display in blue color.
2. Input ‘1’ from the keyboard and choose the unit ‘1’. The mean is set to 1V.
When the stdev and mean are set, the noise generated is shown in Figure 3-5.
Figure 3-5 Generate a Noise
