SDG2000X User Manual 81
2.12 To Store and Recall
SDG2000X can store the current instrument state and user-defined arbitrary
waveform data in internal or external memory and recall them when needed.
Press Store/Recall to enter the following interface.
Figure 2-42 Store/Recall Interface (Page 1/2)
Table 2-24 Menu Explanations of Save and Recall
Function
Menu
Settings
Explanation
File Type
State
The setting of the generator;
Data
Arbitrary waveform file
Browse
View the current directory.
Save
Save the waveform to the specified path.
Recall
Recall the waveform or setting information in the specific
position of the memory.
Delete
Delete the selected file.
Page
1/2
Enter the next page.
