138 SDG2000X User Manual
3.7 Example7: Generate a Linear Sweep Waveform
Generate a sine sweep waveform whose frequency starts at 100Hz and
sweeps to a frequency of 10KHz. Use internal trigger mode, linear sweep, and
a sweep time of 2s.
 Steps:
 Set the sweep function.
Press Waveforms and choose the sine waveform as the sweep function.
The default setting of the source is internal.
 Set the amplitude and offset.
1. Press Amplitude/HighLevel to choose Amplitude which will display in blue
color. Input ‘5’ from the keyboard and choose the unit ‘Vpp’ to set the
amplitude to 5Vpp.
2. Press Offset/LowLevel to choose Offset which will display in blue color.
Input ‘0’ from the keyboard and choose the unit ‘Vdc’ to set the offset to
0Vdc
 Set the sweep time.
Press Sweep → Page 1/2 → Sweep Time, input ‘1’ from the keyboard and
choose the unit ‘s’ to set the sweep time to 1s.
 Set the start frequency.
Press StartFreq, input ‘100’ from the keyboard and choose the unit ‘Hz’ to
set the start freq to 100Hz.
 Set the stop frequency.
Press StopFreq, input ‘10’ from the keyboard and choose the unit ‘kHz’ to
set the stop freq to 10kHz.
 Set the sweep profiles.
