SIGLENT
46 SDG2000X User Manual
Waveform of the low frequency pulse electrotherapy
Waveform 1 of the nerve stimulation electrotherapy
Waveform 2 of the nerve stimulation electrotherapy
Waveform 3 of the nerve stimulation electrotherapy
Sectional pulse FM signal
Sectional sine PM signal l
TureArb waveform 1（375 pts）
TureArb waveform 1（16384 pts）
TureArb waveform 2（3000 pts）
TureArb waveform 2（16384 pts）
2. To Select the Stored Waveform
Choose Waveforms → Page 1/2 → Arb → Arb Type → Stored Waveforms to
enter the following interface, as shown in Figure 2-22.
Figure 2-22 Stored Waveform Display Interface
