58 SDG2000X User Manual
Noise
Arb
FM Freq
Set the modulating waveform frequency. Frequency
range 1mHz~1MHz (internal source).
To Set Frequency Deviation
Press FM Dev to highlight the parameter, and then use the numeric keyboard
or arrow keys and knob to input the desired value.
 The deviation should be equal to or less than the carrier frequency.
 The sum of the deviation and the carrier frequency should be equal to or
less than maximum frequency of the selected carrier waveform.
Note:
The methods of setting other parameters of FM are similar to AM.
