20
LENS CAP
To preserve the lens, the lens cap is
attached. If you do not use the camera,
please keep the lens cap attached.
Attach or remove the lens cap as shown
in the illustration.
LOADING THE BATTERY
A lithium-ion battery, BP-51, is provided with the dp3 Quattro camera.
Charge the battery before using the camera for the first time. Charge the
battery by the supplied battery charger, BC-51, when the battery is empty.
TO CHARGE THE BATTERY
1
Attach the battery by sliding it in the direction
of the arrow, as shown in the diagram.
2
Connect the power cable to the charger
and insert the plug into the wall outlet.
