LOADING THE BATTERY
A lithium-ion battery, BP-61, is provided with the sd Quattro camera.
Charge the battery before using the camera for the first time. Charge the
battery by the supplied battery charger, BC-61, when the battery is empty.
TO CHARGE THE BATTERY
1
Attach the battery by sliding it in the
direction of the arrow, as shown in the
diagram.
2
Connect the power cable to the charger
and insert the plug into the wall outlet.
The charge lamp will be green whilst the
battery is charging
It takes about 220 minutes to recharge
the battery.
Required time for recharging the battery
depends on the ambient temperature
and status of recharge level.
